I've been fixing my own cars for nearly 45 years. All headlight bulbs on every car and truck I've owned were removed basically the same way. I hate the headlights on our new 2025 CX-5. You go over the slightest downward incline and you can't see where your going. I decided to explore the option of going back to a regular style lightbulb. I thought I would start by pulling the low beam bulb and getting a number off it, and looking at the style. Then I was going to see if my local NAPA could help me. I believe the bulbs on the car are LED. Tonight I went to pull out the bulb and created a major problem. I removed the harness, and then turned what I thought was the bulb. Instead the fitting fell inside the cavity of the light fixture. I spent 2 hours messing around and I can't get it back out. To make matters worse, it's not even the bulb!! The fitting is wired to what appears to be the bulb deep inside the light fixture. Any skilled mechanics know how to get the fitting out that fell into the cavity? Thanks so much in advance!



After 4 hours, I finally was able to fish out the harness from inside the light assembly cavity. What a stupid design. I still don’t know how to find the low beam bulb. For those confused by my post, Mazda must’ve changed the design in 2025, or shortly prior. The previous headlight bulbs were much like a traditional bulb. In this model, when you disconnect the lighting harness, you see what looks like a traditional bulb with the butt end sticking out. You would assume you just twist it, and the bulb end just comes right out. Wrong! It’s actually another harness that will fall into a cavity. Fortunately, there are wires sticking out the other end of this harness, but grabbing the wires and trying to pull the harness out of the hole is impossible. I was able to grab the harness with a hooked tool, and with several tries able to position it so I could then pull it up through the hole until it won’t come out any further. Then I very carefully grasped the butt end and twisted it into place. Then I was able to snap back on the first harness.



In the future and for any service work it may be worth while to get the proper service steps. You can get a complete service guide used by both Aida and independent service shops for under 20 usd . ALLData .



Thanks for the tip! As you must already know, that's $20 for 30 days access.



Double posted response ops.



Yes. And you or anyone should take advantage of that 30 day for 20 bucks and download a complete comprehensive service manual for their year and model of vehicle. My cost for AllData is several hundred dollars that we pay annually through the shop. But it’s more comprehensive and gives more detail about hourly service jobs both retail and related to dealer warranty replacement of parts and service. Now mind you our contract does not allow me to post the service copied information from ALLData however many of the responses on this and many other forums are from our commercial account and for this forum specifically Mazda service information that ALLData has permission via Mazda to use as service advisories and such for subscribed service commercial accounts.



Thanks so much for the tip and reply! I didn't realize you could download a complete manual. I assumed that the ALLData service was like others, where you could only access portions of a repair manual, not the entire manual. A bargain for $20, so I decided to go ahead. Unfortunately they have no Mazda 2025 manuals of any models, or 2024 for that matter. I'm reluctant to pay and download the 2023 repair manual, as I'm thinking Mazda changed the low beam bulb access in the last year or two (changing it to a ridiculous design). I read somewhere that you might have to remove the front bumper and then the entire lighting assembly just to change the bulb. I would've gladly paid the $20 to get the repair manual for my 2020 F250, but they don't have that either. I would welcome any other resources you might know of. Thanks again!



You need to contact them direct not the website as it is not completely updated for all the platforms and model for 2025. The obvious reason is for DIY or most service shop they and not really needed because of either warranty or most all services should be done at a dearer ship for that platform for the first 6 months from production date.
There is not really a complete manual for DIY but an hour spent to download the several hundred pages is not difficult. Sorta cheating the system .

sorry for some reason my internet won’t let me look at USA ALLData info nor will it let me log onto my service account. We are on vacation in Ireland at the moment .



In the future, if you need repair manuals, you can visit uzicar.com. I often use the guides on this site to support my car repair work.



That is a good website but it is missing important information for service work and not the best choice. But to be clear it is still a good place for a garage home DIY that has basic level service experience.
More or less like a Chiltons,Haynes or Clymer type service manual.
